Hyundai excavator - R220LC-7 MaGiQ

ReflowX SKU: REF-3334

Product Details

Quantity

1
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

Hyundai Construction Equipment India Pvt. Ltd.
Equipment code

Get Quotation Whatsapp

Short Description

Manufacturer: Hyundai Construction Equipment India Pvt. Ltd. Model: R220LC-7 MaGiQ Equipment Type: Excavator Serial Number: HHKHKD01S7NAG0109 Operating Weight: 22,300 kg Engine Power: 147 HP / 110 kW / 1950 rpm Manufacturing Location: Plot No. A-2, MIDC Chakan, Phase-II, Pune 410 501, India

Description

Specifications

General Information

Brand: Hyundai

Model: R220LC-7 MaGiQ

Type: Crawler Excavator

Engine Power: 129 kW (173 HP)

Operating Weight: 22,000 kg (48,500 lbs)

Bucket Capacity: 1.0 m³ (1.3 yd³)

Engine Specifications

Engine Model: Cummins QSB6.7

Engine Type: 6-Cylinder, Turbocharged Diesel

Power Output: 129 kW (173 HP) @ 2,000 rpm

Displacement: 6.7 L

Fuel Tank Capacity: 400 L

Emission Standard: Tier 3

Lifting & Digging Performance

Maximum Digging Depth: 6,580 mm (21.6 ft)

Maximum Reach at Ground Level: 9,270 mm (30.4 ft)

Maximum Dumping Height: 6,460 mm (21.2 ft)

Maximum Vertical Wall Digging Depth: 5,380 mm (17.6 ft)

Bucket Digging Force: 13,400 kg (29,541 lbs)

Arm Digging Force: 9,120 kg (20,099 lbs)

Hydraulic System

Pump Type: Variable Displacement Piston Pump

Hydraulic Flow: 543 L/min

Operating Pressure: 350 bar

Dimensions & Weight

Overall Length: 9,320 mm (30.5 ft)

Overall Width: 2,950 mm (9.7 ft)

Overall Height: 3,330 mm (10.9 ft)

Undercarriage Length: 4,080 mm (13.4 ft)

Track Width: 600 mm (2.0 ft)

Track Length on Ground: 3,600 mm (11.8 ft)

Ground Clearance: 450 mm (1.5 ft)

Operating Weight: 22,000 kg (48,500 lbs)

Undercarriage & Mobility

Tracks: Heavy-duty, Steel Tracks

Drive Type: 2-Speed, High and Low Mode

Maximum Travel Speed: 5.5 km/h (3.4 mph)

Maximum Swing Speed: 10.5 rpm

Gradeability: 30%

Operational & Safety Features

MaGiQ Control System for Efficient Operations

Advanced Load Sensing Hydraulics for Precision

ROPS/FOPS Certified Operator’s Cabin for Safety

Joystick and Lever Control Options

Self-Diagnostic System for Optimal Performance

Hydraulic Quick Coupler Option for Fast Attachments

Air Conditioning and Ergonomic Seating for Operator Comfort

Heavy-Duty Components for Increased Durability

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Model Number	Hyundai: R220LC-7 MaGiQ
Height	3,330 mm (10.9 ft)
Width	2,950 mm (9.7 ft)
Length	9,320 mm (30.5 ft)
Weight	22,000 kg
Color	Yellow
Fuel type	Diesel

General Terms

ReflowX and the seller retain the right to evaluate and approve offers.
Buyers should verify quantities and conditions upon delivery.
After successful engagement, both buyer and seller manage communication for payment terms and delivery schedule.
All parties agree to adhere to ReflowX Terms and Conditions in transactions.
Buyers can request value-added services such as pre-purchase inspections, Expediting & Delivery Services through ReflowX. Contact us!
