General Information

Manufacturer: Claudius Peters Technologies GmbH (Made in Germany)

Model: GM 25 S

Order Number: 213783

Machine Number: 16401

Year of Construction: 2011

Type: Industrial High-Pressure Air Handling Machine

Medium: Air (Designed for pneumatic conveying and material transport applications)

 Performance & Operating Data

Speed: 3480 RPM (High-speed operation for efficient airflow and pressure control)

Power Consumption: 36.75 kW (Optimized for energy-efficient performance)

Suction Pressure: 1.000 bar (Atmospheric Pressure) (Operates at normal atmospheric conditions on the intake side)

Overpressure (Pe): 0.800 bar (Generates significant pressure for pneumatic transport systems)

Maximum Operating Temperature: 135°C (Suitable for high-temperature industrial environments)

Airflow Capacity: (Not specified but expected in line with Claudius Peters' high-performance range)

Drive System: Electric Motor-Driven

 Construction & Design Features

Material: Heavy-duty industrial-grade steel construction for durability

Cooling System: Air-cooled system for continuous operation

Lubrication: Automatic lubrication system for minimal maintenance

Bearings: High-performance bearings designed for high-speed operation

 Applications

🔹 Pneumatic Conveying Systems (Bulk material transport in cement, gypsum, and minerals industries)
🔹 Industrial Air Handling (Filtration, drying, and aeration systems)
🔹 Dust Collection & Environmental Control (Managing air quality in manufacturing plants)
🔹 High-Pressure Air Supply (For combustion, cooling, and aeration applications)
🔹 Cement & Gypsum Processing (Integrated into bulk material handling and transport systems)

 Environmental & Operational Conditions

Ambient Temperature Range: -10°C to +50°C

Humidity Tolerance: 95% RH (non-condensing)

Noise Level: Compliant with industrial noise standards (Exact dB level not specified)

 Certifications & Compliance

CE Certified (Meets European safety and operational standards)

ISO 9001: Quality management compliance

IEC 60034: Electrical efficiency and safety standard

EN 60079: Explosion protection (if applicable)

DIN Standards Compliance: Ensures German manufacturing precision


For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
